Cable and Accessories
M DRUM XS 100/2
65LSD104
Audio
25 m
Potencia
Audio and power cable with reel
25 meters of professional cable hose reelwith high resistance, desogned for active speakers. The cable combines a Powercon connection and a XLR cable to send the signal.
The diameter of the cable is 13mm and incorporates on the base 4 connections, two of them are XLR and two Powercon.
Features
- XLR3 aerial male - XLR3 base male/female connectors.
- IEC C13 power connectors - 2xAC 3-pin.
- 25 m length cable.
- Black.
| Type | Audio signal and power supply |
| Connections | Audio signal: XLR3 aerial male - XLR3 base male/female. Power supply: IEC C13 - 2xAC 3-pin |
| Length | 25 metros/ 25 m |
| Diameter | 13 mm |
| AWG | 24 |
| Conductors | Audio signal: 2 x 0.22 mm². Power supply: 3 x 1.0 mm². |
| Threads per conductor | Audio signal: 28 x 0.10 mm |
| Conductor insulation | PE 1.40 mm |
| Shield | Copper coiled shielding 48 x 0.10 mm + AL / PT foil |
| Shield factor | 100 % |
| Temperature range | -20 ºC to +70 ºC |
| Conductor capacitance | Audio signal: 124 pF/m |
| Shield capacitance | Audio signal: 55 Ohm |
| Colour | Black |
25 meters of professional cable hose reelwith high resistance, desogned for active speakers. The cable combines a Powercon connection and a XLR cable to send the signal.
The diameter of the cable is 13mm and incorporates on the base 4 connections, two of them are XLR and two Powercon.
The diameter of the cable is 13mm and incorporates on the base 4 connections, two of them are XLR and two Powercon.
